LEDXION AEROS II
Indoor Lighting
Product Description
LUMINAIRE SPECIFICATION
- Power 480W 720W
- Fitting Material 316 Grade Stainless Steel
- Optical Cover High Transparency Polycarbonate
- Ingress Protection IP66
- Impact Protection IK08
- Voltage 220 ~ 240 Vac 50 / 60Hz
- Electrical Safety Class Class I
- OperatingTemperature -30 ~ +45 C
- Installation Mounting Bracket
- Surge Protections 10KV, 20KA
OPTIONAL FEATURES (UPON REQUEST)
- Driver Constant Current, 1-10V Dimming, DALI
- Beam Angle Narrow Beam
- Medium Beam
- Asymmetrical
- Power Cable 2m (Pre-Wire)
- 5m, 10m, 15m & 20m (Optional)
LED MODULE SPECIFICATIONS
- LEDType 5050
- Color Temperature 3000K Warm White 4000K Neutral White 5000K Cool White
- Color Rendering Index >70 (CRI) >90 ( Upon Request)
- L70 100,000 Hrs @ 25 C
- PCB Material Metal Core (Alumina)
- SMD Connector WAGO 2060 Series
COMPLIANCE STANDARD
- LED LM80, UL, RoHS
- Driver CE, EN62493, EN61347, EN50581, EN55015, EN61000, EN61547, EN62384
- Luminaire EN60598-1, EN60598-2-5, EN62493, EN55015, EN61547, EN61000, EN62471, CISPR 15
APPLICATION
- Sport Lightings, Stadium Lightings, Jetties & Highmasts
