LUMINAIRE SPECIFICATIONS

• Power - 20W 40W
• Fitting Material - Non-Corrosive Die-Cast Aluminium
• Fitting Color - Black, Akzo Nobel RAL9005
• Optical Cover - Frosted Polycarbonate Diffuser
• Ingress Protection - IP65
• Impact Protection - IK08
• Voltage - 220 ~ 240 Vac 50 / 60Hz
• Electrical Safety Class - Class I
• Operating Temperature - -30 ~ +400C
• Installation - Wall Mounting
• Surge Protections - 10KV, 20KA

LED MODULE SPECIFICATIONS

• Color Temperature – 20W – 3000K Warm White – 6500K Daylight 40W – 3000K Warm White – 4000K Neutral White- 5000K Cool White
• Color Rendering Index – 20W – >80 Warm White (CRI) 40W – >70 Cool White & Neutral White – >80 Warm White
• L70 – 100,000 Hrs @ 250C
• PCB Material – 20W – Metal Core 40W – Ceramic (Alumina Substrate)
• PCB Trace – Silver
• SMD Connector – WAGO 2060 Series

COMPLIANCE STANDARD

• LED – LM80, UL, RoHS
• Driver  – CE, EN62493, EN61347, EN50581, EN55015, EN61000, EN61547, EN62384

APPLICATION

• Facade Lightings, Praying Halls, Corridors, Passage Ways,
  Exhibition Halls
